The turning radius on a forklift is also known as the turning circle. This information is essential for a machine operator to have. It gives the operator the knowledge of how much space is required to turn the forklift around. For instance, a tighter turning radius enables the machine to successfully work in tight places and congested areas, therefore enhancing the maneuverability of the lift truck. Drivers who do not know this measurement could cause damage to the equipment or to the property.
Make the necessary steering geometry alignment corrections prior to checking the turning radius. The test must start with an operator trainer assisting in the cab where they can help to control the machine's functions. Another individual on the ground utilizes a hose or a spray bottle to wet the outside and inside of the model's wheels. Next, drive the equipment in a whole circle with the wheels turned to the maximum angle. Repeat the procedure once and if necessary, continue to wet the wheels.
Measure the watermarks left by the tires using a tape measure after your measurement test has been done. The watermark test starts from the tire mark's midpoint to a similar point across the circle's diameter. For the outside turning diameter, measure the watermark left by the exterior tires from the circle's one side to the opposite side of the circle. You could determine the inside turning radius by stretching the tape measure across the circle left by the inner tires. Next, divide these numbers in 2 to be able to establish the turning radius. Be certain to note that the turning center is the midpoint of the diameter of the circle.
In order to establish the wall-to-wall turning diameter, drop a plumb line from the extreme outside radial extension on the machinery. After this is accomplished, the next step is to locate the point on the pavement directly underneath. This point to the turning center indicates the clearance radius of the equipment. As a rule, wall-to-wall turning diameter is twice the vehicle clearance radius.
